MICROSUN

The ultra-powerful MicroSun™ LED is very versatile, with the ability to be mounted almost anywhere on an aircraft. In addition to its standard operation as a landing and taxi light, the MicroSun™ features integrated Pulse or “WigWag” significantly increasing recognition in broad daylight as well as night operations to help avoid midair collisions and bird strikes while drawing half the current. Their compact profile makes them the perfect option for lighter weight Experimental or Kit planes.

  • Power consumption: 24 watts max
  • Higher color temperature – White
  • Built-in pulse mode
SKU: MICROSUN-I Category:
SKU Price Buy Cart
SKU: MICROSUN-E Voltage : 9 - 40 Style: EXTERNAL MOUNT Price: $350.00
Quantity
Ships in 7-10 Days
or Add to Wishlist
SKU: MICROSUN-I Voltage : 9 - 40 Style: INTERNAL MOUNT Price: $350.00
Quantity
Ships in 7-10 Days
or Add to Wishlist

Description

MICROSUN LED TECHNICAL SPECIFICATIONS

MicroSun MicroSun External Mount
Part Number 01-1170 01-1170A
Voltage 9-40 9-40
Power 24 Watts 24 Watts
Wigwag Yes Yes
Synchronization Yes Yes
Lumens 2,640 2,640
Candela 15,000 15,000
Beam Profile 30 x 30 30 x 30
Length 3.1″ 3.1″
Width 1.9″ 1.9″
Depth 2.0″ 0.9″
Weight 3.60 oz 2.2 oz
